Intel Cyclone V SoC SE series / Compact Module

ArmFrogs-ALICE



Compact SoM with Arm core-embedded FPGA. (System-on-Module)
Broadly compatible with products from embedded devices to educational materials.
Also available for research into countermeasures against side-channel attacks.


[Simple functionality]
Simple and easy-to-use FPGA board with carefully selected peripheral functions.

[Sample project]
A sample project created with Intel's Quartus Prime Lite Edition (free version) is included.

[Abundant IOs for expansion]
Expansion IOs for differential signaling and single-ended signaling are provided for flexible response to functional expansion.

[Expansion board support]
Various functions as industrial equipment can be realized with expansion boards.
GopherTec handles everything from the specification design to the production of expansion boards.

[Design service]
We can handle FPGA logic design and even design and manufacture boards for functional expansion.
We realize the design of various processes by relying on our extensive experience in embedded devices.

[Optimal for research into countermeasures against side-channel attacks (attacks on encryption) *1]
It is optimal for research into side-channel attacks, in which cryptographic keys are deduced by observing the noise generated in the power supply.
It has three types of power supply observation points: soldering pads, probing points, and SMA connectors. There is also a version without the FPGA core power supply’s bypass capacitor.
*1: GopherTec is researching countermeasures against side-channel attacks for cryptographic functions (AES cipher, elliptic curve cipher, etc.) implemented in FPGAs.

[Ideal for educational materials]
The simple, easy-to-use design makes it ideal for introductory use in FPGAs and for educational materials.
We can design FPGA sample projects and exercises for educational materials.

ArmFrogs is a registered trademark of GopherTec.Inc.
Intel, the Intel logo, and Intel Cyclone are trademarks of Intel Corporation in the United States and other countries.
The TM and ® marks may be omitted at the time of description.
*Components mounted may differ depending on variations, etc.
*Product appearance and functional specifications are subject to change without notice.
